Launch X-631 Wheel Aligner Maintenance Manual Maintenance and Testing for Measurement Probe Rod

3-4

Note: According to the above figure, plug two black leads of the battery together, connect two probes of

multi-meter (at AC/DC shift) to the other two red leads respectively (to form a complete serial circuit), and

then plug the charging cable of the probe rod. Check if the charging current is normal or not (If the battery

has no electricity, the charging current is about 600mA; if the electricity quantity of the battery is sufficient,

the charging current is only between 20 and 100 mA).

Item18: Wheel Clamp Axle Inspection

Note: Clear the wheel clamp axle, check if it is rusty, and lubricate it with appropriate oil

Current shift

Wheel clamp axle
