Launch X-631 Wheel Aligner Maintenance Manual Probe Rod Calibration

5-4

c) Calibration for 1# and 2# clinometer and end CCD camera

First, please remove the two vertical axles from the small calibration frame, and then install 1# and 2# probe rods at

the two ends of the long lateral axle of calibration frame and adjust them level, as shown in the following figure:

d) Calibrate 3# and 4# probe rod clinometer and end CCD (the operating methods are the same with the

Computer interface

Lateral axle level bubble

横轴水平泡

Vertical axle level bubble

纵轴水平泡
