Page 28PROTECTOR® IV Top of Rail Installation, Operation & Maintenance Manual
200/25 AC AND DC TANK PART NUMBERS
Part Number Quantity Material Description
788-30021-84 1 AC P-IV 200# Tank and Pump Assembly (Single Pump)
788-30021-80 1 DC P-IV 200# Tank and Single Pump Assembly (Single Pump)
788-30025-80 1 DC P-IV 200# Tank and Pump Assembly (Double Pump)
788-30025-84 1 AC P-IV 200# Tank and Pump Assembly (Double Pump)
783-40040-00 1 1 1 1 Battery- 40 AMP HR
788-30004-67 1 1 1 1 AC/DC Power Harness P-IV
788-30007-10 1 1 Motor Pump Assembly (Single Pump)
788-30007-04 1 1 Motor Pump Assembly (Double Pump)
3U-1200 1 1 Replacement for 788-30007-10
788-30008-53 1 1 AC Wiring Diagram
788-30009-04-P 1 1 1 1 Digital Control Box
788-30012-66 1 1 Charger Assembly
788-30020-01RA 1 1 1 1 Tank Protector P-IV 200#
788-30007-53 1 1 1 1 Pump Time Out P-IV 200# Tank
788-30008-56 1 1 DC Wiring Diagram
788-30006-31 1 1 2 2 Hose- ¾” Tank Wall
