Page 40PROTECTOR® IV Top of Rail Installation, Operation & Maintenance Manual
SMART WHEEL SENSOR PART NUMBERS
Item Part Number Quantity Quantity Material Description
788-30009-05-P 1 1 Smart Wheel Sensor Head w/Pigtail
788-3000909-35DM
-50DM
1 1 Sensor Cable
788-50005-50
(includes items 1-7
listed below)
1 Smart Wheel Sensor Package Kit (Standard 112+ lb.)
788-50006-50
(includes items 1 - 7
listed below)
1 Smart Wheel Sensor Package Kit (Small <112 lb.)
1 700-675-039 4 4 C.%T&:"#4*3&p7f]&L')"/;"3;R
2 700-693-075 1 1 Hard Washer ¾” ASTM F-436 ZNC
3 700-845-075 2 2 Hex Nut UNC Zinc ¾”
4 700-893-125 4 jj-'&&`6")*;&p7f]G^g&X-&d&^Ghq
4 700-893-175 4 HHCS Plated p7f]-16 NC x 1-¾"
5 788-30002-14 1 Smart Wheel Sensor Bracket (Standard)
5 788-30002-13 1 Smart Wheel Sensor Bracket (Short)
6 788-300-0215-313 2 2 '+"3)&&:4**6&&'*/#.3&&'<"%*3&r7[\q&L`"$3R
7 900-031-272 1 1 J-Bolt ¾” x 10-½” Zinc Plated
