Page 31PROTECTOR® IV Top of Rail Installation, Operation & Maintenance Manual
SOLAR PANEL AND POLE KIT PART NUMBERS
Item Part Number Quantity Material Description
1 788-80001-00 1 Solar Panel Pole Kit
2 788-30001-02 1 Solar Panel
3 788-30007-95 1
Voltage Regulator with
Bracket
DOUBLE PUMP MOTOR ASSEMBLY PART NUMBERS
Item Part Number Quantity Material Description
788-30007-04 1
Double Pump Motor
Assembly (Ductile)
1 3M-3005 1
Coupler between Motor
and Pump
2 3M-3006 1
Motor Mount between
Motor and Pump
3 788-51055-00 1 Double Pump Ductile Iron
4 713-506-016S 10
SHCS M6 x 1mm x 16mm
GR.12.9 SS
5 713-40600-0Z 4 M6 Elastic Locknut
6 713-50604-0S 4
SHCS M6 x 1mm x 40mm
GR.12.9 SS
7 788-51049-00 1 Gasket
8 788-30007-12 1
DC Gear Motor with
Connector (P-IV)
9 788-51053-00 1
Double Pump Mounting
Plate
Not
shown
788-31046-01
(must be ordered
separately)
1
Tank Wall to Pump Plate
Gasket
To Next Page
