Page 35PROTECTOR® IV Top of Rail Installation, Operation & Maintenance Manual
TOR ML
-
BAR PART NUMBERS
Item Part Number Quantity Material Description
788-07066-50 1 TOR ML-Bar Assembly
1 788-01217-00 1 Manifold
2 788-01218-00 1 Cover Plate
3 788-01219-00 1 Top Seal #1
4 788-01220-00 1 Top Seal #2 (undercut front)
5 503-526-000 8 M10 SS Shoulder Bolt (hex style head)
6 503-525-000 32 SS Belleville Springs
7 788-01200-00 3' Clip-on Back Seal
