Page 38PROTECTOR® IV Top of Rail Installation, Operation & Maintenance Manual
QUICK MOUNTING CLAMP PART NUMBERS
Item Part Number Quantity Quantity Material Description
788-07092-50 1 Quick Clamp Sub-Assembly (Standard)
788-07092-51 1 Quick Clamp Sub-Assembly (Small)
1 788-07079-50 1 1 Quick Cam Assembly
2 788-01179-00 1 TOR XL Rail Clamp Body (Small)
3 788-01161-00 1 1 Dual Keyed Hardened Washer
4 788-01081-00 3 3 3/8” Spacer
5 700-836-300 1 1 Hex Head Screw ¾” UNC x 3” Zinc
6 700-675-077 1 1 ¾” Lockwasher Zinc Plated
7 788-01160-50 1 TOR XL Rail Clamp Body (Standard)
8 700-694-075 4 4 ¾” USS Hard Flat Washer Zinc
9 956-00025-81 2 1 Open End Spacer
