2
G6A Low Signal Relay
G
6
A
■Ratings
●Coil: Single-side Stable (Standard Models)
Note1. The rated current and coil resistance are measured at a coil temperature of 23°C with a tolerance of ±10%.
2. Operating characteristics are measured at a coil temperature of 23°C.
3. The maximum voltage is the highest voltage that can be imposed on the relay coil.
●Coil: Single-side Stable (Low-sensitivity Models)
Note1. The rated current and coil resistance are measured at a coil temperature of 23°C with a tolerance of ±10%.
2. Operating characteristics are measured at a coil temperature of 23°C.
3. The maximum voltage is the highest voltage that can be imposed on the relay coil.
●Coil: Single-side Stable (High-sensitivity Models)
Note1. The rated current and coil resistance are measured at a coil temperature of 23°C with a tolerance of ±10%.
2. Operating characteristics are measured at a coil temperature of 23°C.
3. The maximum voltage is the highest voltage that can be imposed on the relay coil.
●Coil: Single-winding Latching
Note1. The rated current and coil resistance are measured at a coil temperature of 23°C with a tolerance of ±10%.
2. Operating characteristics are measured at a coil temperature of 23°C.
3. The maximum voltage is the highest voltage that can be imposed on the relay coil.
Contact form Rated voltage
Rated current
(mA)
Coil resistance
(Ω)
Must operate voltage
(V)
Must release voltage
(V)
Max. voltage
(V)
Power consumption
(mW)
% of rated voltage
DPDT (2c)
3 VDC 66.7 45
70% max. 10% min.
200%
(at 23°C)
Approx. 200
4.5 VDC 44.6 101
5 VDC 40.0 125
6 VDC 33.3 180
9 VDC 22.2 405
12 VDC 16.7 720
24 VDC 8.3 2,880
48 VDC 4.9 9,750 Approx. 235
Contact form Rated voltage
Rated current
(mA)
Coil resistance
(Ω)
Must operate voltage
(V)
Must release voltage
(V)
Max. voltage
(V)
Power consumption
(mW)
% of rated voltage
DPDT (2c)
3 VDC 133.3 22.5
70% max. 10% min.
150%
(at 23°C)
Approx. 400
5 VDC 80 62.5
6 VDC 66.7 90
9 VDC 44.3 203
12 VDC 33.3 360
24 VDC 16.7 1,440
48 VDC 8.3 5,760
Contact form Rated voltage
Rated current
(mA)
Coil resistance
(Ω)
Must operate voltage
(V)
Must release voltage
(V)
Max. voltage
(V)
Power consumption
(mW)
% of rated voltage
DPDT (2c)
3 VDC 50 60
80% max. 10% min.
200%
(at 23°C)
Approx. 150
4.5 VDC 33.3 135
5 VDC 30 167
6 VDC 25 240
9 VDC 16.7 540
12 VDC 12.5 960
24 VDC 6.3 3,840
48 VDC 3.2 15,000
Contact form Rated voltage
Rated current
(mA)
Coil resistance
(Ω)
Set voltage (V) Reset voltage (V) Max. voltage (V)
Power consumption
(mW)
% of rated voltage
DPDT (2c)
3 VDC 33.7 89
70% max. 70% max.
200%
(at 23°C)
Approx. 100
5 VDC 20 250
6 VDC 16.7 360
9 VDC 11.1 810
12 VDC 8.3 1,440
24 VDC 4.2 5,760
48 VDC 2.5 19,000 Approx. 120
