142 Service & Repair
Removal of Pushout Panel
For this task, apply the following procedure:
1. Move the pushout lever rearward and position the pushout panel at the extreme rear of the body.
2. Remove the tailgate lift cylinders as described on Page 126.
3. Remove the tailgate as described on Page 129.
4. Disconnect the telescopic pushout cylinder from the pushout panel.
5. Weld an eye to the center of the panel and attach a chain to prevent the panel from tipping over
upon removal.
OPERATIONAL STATUS
Truck Running PTO Engaged Speed Up On
WEAR BLOCKS
PUSHOUT
LEVER
To Next Page
