Leach 2R-III - Checking Accessory (Circuit) Relief Cartridge

Check-Out 69
Checking Accessory (Circuit) Relief Cartridge
Use the test fixture and test as shown on illustration.
OPERATIONAL STATUS
Truck Off PTO Disengaged
Attach port-a-power
with 0-3000 psi
gauge to port
marked “P2”
When the adjusted
pressure is reached
(1700 psi), fluid will
drain from port
marked “T2”
Install relief
cartridge in port
marked “SP”. Tighten
to 20 ft. lbs
Locking nut
Part #HYV50000
