Leach 2R-III - Hydraulic Fitting Torque Values

40 General Repair Practices
Hydraulic Fitting Torque Values
JIC 37 DEGREE FLARED TUBE FITTINGS
SAE
DASH
SIZE
TUBE SIDE
THREAD
SIZE
TORQUE
INCH LBS.
TORQUE
FOOT LBS.
FLAT FACE O-RING (ORFS) FITTINGS
SAE
DASH
SIZE
TUBE SIDE
THREAD
SIZE
TORQUE
INCH LBS.
TORQUE
FOOT LBS.
2 5/16-24 35 2
3 3/8-24 65 5
4 7/16-20 130 11
5 1/2-20 165 14
6 9/16-18 235 20
8 3/4-16 525 43
10 7/8-14 650 55
12 1 1/16-12 950 80
14 1 3/16-12 1200 100
16 1 5/16-12 1400 115
20 1 5/8-12 1900 160
24 1 7/8-12 2250 185
32 2 1/2-12 3000 250
4 9/16-18 220 18
6 11/16-16 360 30
8 13/16-16 480 40
10 1-14 60
12 1 3/16-12 85
14 1 5/16-12 95
16 1 7/16-12 110
20 1 11/16-12 140
24 2-12 180
32 2 1/2-12 360
