LEAD FLUID BT600S - Page 29

LEAD FLUID TECHNOLOGY CO.,LTD.
11 Specifications
Speed resolution 0.1-100 rpm, 0.1 rpm resolution;
100-600 rpm, 1 rpm resolution
Speed accuracy
0.5%
Power supply AC 220V ± 10% 50Hz/60Hz;
AC 110V ± 10% 50Hz/60Hz
Power consumption BT100S: < 40W; BT300S:< 50W;
BT600S:< 60W
External logic level control
signal
5V, 12V (standard), 24V (optional)
External analog control
signal
0-5V (standard); 0-10V, 4-20mA (optional)
Communication interface RS485 MODBUS
Operating condition
Temperature 0~40°C
Relative humidity <80%
IP grade IP31
Display 132x32 LCD
Dimensions (LxWxH) 226 x 150 x 238 mm
(8.90 x 5.91 x 9.37 inch)
Weight BT100S: 4.7 kg (10.4 lbs)
BT300S: 4.9 kg (10.8 lbs)
BT600S: 5.2 kg(11.5 lbs)
Mail：master@leadfluid.com WEB：www.leadfluid.com 26
