LEAD FLUID BT600S - 9 Dimensions; 10 Naming Rule

BT/S Variable-Speed Peristaltic Pump
9 Dimensions
150
226
238
Figure 29. Dimensions(mm)
10 Naming Rule
TB
1
0
0
S
Drive Type
B: Step motor
W
: DC brushless
motor
J: AC motor
F: Explosion Proof
Motor
Z: DC motor
1
65
Function Code
1-9
for special
pumps
Version
0-9
Rotation Speed
05: 50 rpm
08: 80 rpm
10: 150 rpm *
30: 350 rpm
60: 600 rpm
Flow Rate
Q: Microflow
T: Laboratory
G: Industrial
P: Batch transfer
IP rating
Default:
IP31
Pump type
D: Fixed speed
S: Variable speed
L: Flow pump
F
: Dispensing
pump
* BT
102S: 100 rpm
