BT/S Variable-Speed Peristaltic Pump
PRIME key. Press the key to run pump at maximum allowed speed
in the direction shown on the display. Press again to return to the
previous state.
START/STOP key. Press to start or stop the drive.
4.2 Digital Display
Figure 3.Display screen
4.2.1 A. Control Mode
It displays current control mode. Press MODE key to switch the control
mode: Internal Control mode, External Control mode, Time Dispense mode,
Logic Level 1 control mode or Logic Level 2 Control mode.
• Internal Control Mode: Use the keypad to operate pump. Use
optional external pulse signal to control start and stop.
• External Control Mode: Use external analog signal to control rotation
speed. Use external logic level signal to control direction, start and
stop. The keypad is disabled.
• Time Dispense Mode: Dispense fluid automatically by setting
duration for each dose, time between doses and number of cycles.
• Logic Level 1 Control Mode (footswitch): Use external logic level
signal to control start and stop. Use the keypad to control direction
5 Tel：0312-3250677 3250877 3250977 Fax：0312-3250877-804
