Wall Mount (Optional)
Notes:
Check for reception strength and the Baby Unit's viewing angle before drilling the holes.
The types of screws and anchors you need depend on the composition of the wall. You may need to purchase the
screws and anchors separately to mount your Baby Units.
1. Place the wall mount bracket on a wall and then use a pencil to mark the top and the
bottom holes as shown. Remove the wall mount bracket and drill two holes in the wall
(5.5 mm drill bit).
2. If you drill the holes into a stud, go to step 3.
If you drill the holes into an object other than a stud, insert the wall anchors into
the holes. Tap gently on the ends with a hammer until the wall anchors are flush
with the wall.
