25
Commissioning
Code Possible Settings
IMPORTANT
No. Name Default Selection
Note
P110 = 0, 2: Start command must be applied at least 2 seconds
after power-up;
F.UF fault will occur if start command is applied too
soon.
P110 = 1, 3…6: For automatic start/restart, the start source must be
the terminal strip and the start command must be present.
P110 = 2, 4…6: If P175=999.9, dc braking will be applied for 15s.
P110 = 3…6: Drive will attempt 5 restarts; if all restart attempts fail,
drive displays
LC (fault lockout) and requires manual reset.
P110 = 5, 6: If drive cannot catch the spinning motor, drive will trip
into
F.rF fault.
WARNING!
Automatic starting/restarting may cause damage to equipment and/or injury to personnel!
Automatic starting/restarting should only be used on equipment that is inaccessible to personnel.
P111
Stop Method 0 0 Coast Drive’s output will shut off
immediately upon a stop command,
allowing the motor to coast to a stop
1 Coast with DC Brake The drive’s output will shut off and
then the DC Brake will activate (see
P174, P175)
2 Ramp The drive will ramp the motor to a
stop according to P105 or P126.
3 Ramp with DC Brake The drive will ramp the motor to 0 Hz
and then the DC Brake will activate
(see P174, P175)
P112
Rotation 0 0 Forward Only If PID mode is enabled, reverse
direction is disabled (except for Jog).
1 Forward and Reverse
