Code Possible Settings
IMPORTANT
No. Name Default Selection
P121
P122
P123
p124
TB-13A Input
Function
TB-13B Input
Function
TB-13C Input
Function
TB-13D* Input
Function
0 0 None Disables input
1 AUTO Reference: 0-10 VDC For frequency mode, see P160...P161,
For PID mode, see P204…P205,
For vector torque mode, see P330
2 AUTO Reference: 4-20 mA
3 AUTO Reference: Preset For frequency mode see P131...P137,
For PID mode, see P231…P233,
For torque mode see, P331…P333
4 AUTO Reference: MOP Up • Normally open: Close input to
increase or decrease speed, PID
setpoint or torque setpoint.
• MOP Up is not active while in STOP
5 AUTO Reference: MOP Down
6 AUTO Reference: Keypad
7 AUTO Reference: Network
8 Control Select Use when P100 = 4, 5 to switch
between terminal strip control and
local or remote keypad control.
9 Network Enable Required to start the drive through
the network.
10 Reverse Rotation Open = Forward Closed = Reverse
11 Start Forward
See note for typical circuit
12 Start Reverse
13 Run Forward
See note for typical circuit
14 Run Reverse
15 Jog Forward Jog Forward speed = P134
16 Jog Reverse Jog Reverse speed = P135
WARNING! Active even if P112 = 0
17 Accel/Decel #2 See P125, P126
18 DC Brake See P174; close input to override P175
19 Auxiliary Ramp to Stop Normally closed: Opening input will
ramp drive to STOP according to P127,
even if P111 is set to Coast (0 or 1).
20 Clear Fault Close to reset fault
21 External Fault
F.EF
Normally closed circuit; open to trip
22 Inverse External Fault
F.EF
Normally open circuit; close to trip
23 AUTO Ref: Sequence
Segment #1
Works in Speed Mode only
24 Start Sequence
25 Step Sequence Transition from non-asserted to
asserted state
26 Suspend Sequence
WARNING!
Jog overrides all STOP commands! To stop the drive while in Jog mode, the Jog input must be
deactivated or a fault condition induced.
NOTE: P124 is
applicable to SMV
15HP (11kW) and
greater models
only
