Leeson SPEEDMASTER SM2 Series User Manual

53
Commissioning
Code Possible Settings
IMPORTANT
No. Name Default Selection
P743
Segment #7
Digital Output
State
0
Bit0 Relay bit = 0: OFF (De-energized)
bit = 1: ON (Energized)
The corresponding digital output/
relay must be set to accept value the
Bit1 TB14
P744
Segment #7
TB30
Analog Output
Value
0.00
0.00 {VDC} 10.00 TB30 conguration parameter must
be set to accept this value: P150
= 10
Segment #8
P745
Segment #8
Frequency
Setpoint
0.0
-500.0 {Hz} 500.0 If P112 = 1, negative sign forces
reverse direction
P746
Segment #8
Accel/Decel Time
20.0
0.0 {sec} 3600.0
P747
Segment #8
Time in current
step
0.0
0
0.0 {P708} 6553.5
0 {P708} 65535
Scaling/units depend on P708
Skip segment if time = 0
P748
Segment #8
Digital Output
State
0
Bit0 Relay bit = 0: OFF (De-energized)
bit = 1: ON (Energized)
The corresponding digital output/
relay must be set to accept value the
Bit1 TB14
P749
Segment #8
TB30
Analog Output
Value
0.00
0.00 {VDC} 10.00 TB30 conguration parameter must
be set to accept this value: P150
= 10
Segment #9
P750
Segment #9
Frequency
Setpoint
0.0
-500.0 {Hz} 500.0 If P112 = 1, negative sign forces
reverse direction
P751
Segment #9
Accel/Decel Time
20.0
0.0 {sec} 3600.0
P752
Segment #9
Time in current
step
0.0
0
0.0 {P708} 6553.5
0 {P708} 65535
Scaling/units depend on P708
Skip segment if time = 0
P753
Segment #9
Digital Output
State
0
Bit0 Relay bit = 0: OFF (De-energized)
bit = 1: ON (Energized)
The corresponding digital output/
relay must be set to accept value the
Bit1 TB14
P754
Segment #9
TB30
Analog Output
Value
0.00
0.00 {VDC} 10.00 TB30 conguration parameter must
be set to accept this value: P150
= 10
