Code Possible Settings
IMPORTANT
No. Name Default Selection
Segment #10
P755
Segment #10
Frequency
Setpoint
0.0
-500.0 {Hz} 500.0 If P112 = 1, negative sign forces
reverse direction
P756
Segment #10
Accel/Decel Time
20.0
0.0 {sec} 3600.0
P757
Segment #10
Time in current
step
0.0
0
0.0 {P708} 6553.5
0 {P708} 65535
Scaling/units depend on P708
Skip segment if time = 0
P758
Segment #10
Digital Output
State
0
Bit0 Relay bit = 0: OFF (De-energized)
bit = 1: ON (Energized)
The corresponding digital output/
relay must be set to accept value the
from the sequencer: P140, P142=27
Bit1 TB14
P759
Segment #10
TB30
Analog Output
Value
0.00
0.00 {VDC} 10.00 TB30 conguration parameter must
be set to accept this value: P150
= 10
Segment #11
P760
Segment #11
Frequency
Setpoint
0.0
-500.0 {Hz} 500.0 If P112 = 1, negative sign forces
reverse direction
P761
Segment #11
Accel/Decel Time
20.0
0.0 {sec} 3600.0
P762
Segment #11
Time in current
step
0.0
0
0.0 {P708} 6553.5
0 {P708} 65535
Scaling/units depend on P708
Skip segment if time = 0
P763
Segment #11
Digital Output
State
0
Bit0 Relay bit = 0: OFF (De-energized)
bit = 1: ON (Energized)
The corresponding digital output/
relay must be set to accept value the
from the sequencer: P140, P142=27
Bit1 TB14
P764
Segment #11
TB30
Analog Output
Value
0.00
0.00 {VDC} 10.00 TB30 conguration parameter must
be set to accept this value: P150
= 10
Segment #12
P765
Segment #12
Frequency
Setpoint
0.0
-500.0 {Hz} 500.0 If P112 = 1, negative sign forces
reverse direction
P766
Segment #12
Accel/Decel Time
20.0
0.0 {sec} 3600.0
P767
Segment #12
Time in current
step
0.0
0
0.0 {P708} 6553.5
0 {P708} 65535
Scaling/units depend on P708
Skip segment if time = 0
