3.Operating and Programming
Attach Side Brush to the bottom of robot by pressing a brush into each slot until it clicks.
Install Side Brush
2
1M
1M
2M
Side Brush
3.2 Quick Start
Place the Charging Dock on a level floor surface against the wall with the base perpendicular
to the ground. Keep the immediate area 2m (6.6’) in front of the charger and 1 m (3.3’) on
both sides of the charger clear of objects and reflective surfaces.
Plug the Charging Dock in, the Power Indicator Light on the Charging Dock glows.
Charging Dock Placement
Connect the adapter to the charging Dock
1
Place the Charging DockConnect the power supply
8
