SCS BUS AUTOMATION SYSTEM
WIRING DIAGRAMS
III-130
Single
functions
SWITCHING A LAMP ON AND OFF
SWITCHING TWO LAMPS ON AND OFF WITH ON/OFF GENERAL CONTROL
N
L
321
C1
038 41
321
C1
038 41
1 relay
DIN actuator
16 A
1 relay
DIN actuator
16 A
BUS/SS
ControlControlON/OFF
general
control
Power supply
N
L
321
C1
038 41
Power supply
1 relay
DIN actuator
16 A
To other
devices
SCS BUS
Control
230 Vac
230 Vac
To other
devices
A = 1
PL = 1
M1 = O/I
A = 1
PL = 1
M = –
G1 = –
G2 = –
G3 = –
A = 1
PL = 1
M1 = O/I
A = 1
PL = 1
M = –
G1 = –
G2 = –
G3 = –
A = 1
PL = 2
M = –
G1 = –
G2 = –
G3 = –
A = 1
PL = 2
M1 = O/I
A = GEN
PL = –
M1 = O/I
230 Vac
230
Vac
