CÉLIANE TECHNICAL GUIDE
III-131
sCs Bus automation system
SWITCHING-ON CONTROL FOR BATHROOM LIGHT AND FAN WITH DELAYED SWITCHING-OFF
AUTOMATIC LIGHT SWITCHING-ON AND LOCAL CONTROL OF TIMED ON
OFF
N
L
M
321
C1
038 41
321
C1
038 41
Power supply
1 relay
DIN actuator
16 A
(Master)
To other
devices
SCS BUS
1 relay
DIN actuator
16 A
(Slave)
Control
ON
Bathroom
light
Bathroom
fan
• The light turns on when the IR detector detects a person or
when the control, is pressed. It turns off automatically after
15 minutes.
• The configurators in the AUX positions of the detector and of
the control must have the same value.
N
L
321
C1
038 41
Power supply
1 relay
DIN actuator
16 A
To other
devices
SCS BUS
ControlIR detector
• The ON control turns on the light and the fan at the same time
• The OFF control turns off the light whereas the fan turns off
after 2 minutes (configurator in M=2 of the Master actuator)
230
Vac
230 Vac
A = 3
PL = 1
M1 = O/I
A = 3
PL = 1
M = 2
G1 = –
G2 = –
G3 = –
A = 3
PL = 1
M = SLA
G1 = –
G2 = –
G3 = –
A = 3
PL = 1
M = AUX
SPE = –
AUX = 2
A = 1
PL = 1
M = –
G1 = –
G2 = –
G3 = –
A = 1
PL = 1
M = 6
SPE = –
AUX = 2
230 Vac
230
Vac
