LEHNER SuperVario - Page 39

Operating instructions
Appendix
39
Object Number Description
LEHNER part
number
1 1 SuperVario frame 110/170 RAL 5021 80356
2 1 FrontandoorpanelRAL5021 81555
3 1 Hopper bracket 110 RAL 5021 80342
4 1 SuperVario spreading disc 80472
5 2 SuperVario casting blade VA 81396
6 1 Agitator shaft VA 8x87 with left-hand thread 80376
7 1 Dosage plate PET 4 mm 80281
8 1 Fixing bracket for slide motor RAL 5021 81393
9 1 Dosage plate VA 2 mm 81965
10 15 DIN 125 - A 10.5 -
11 1 SuperVario gasket 18x7.2x2 mm 73215
12 1 SuperVario dosing slide VA 80549
13 2 Ball stud DIN 71803 C8-M5 80415
14 1 Hopper seal 81395
15 1 Hopper mounting PP 80264
16 1 DIN 915 - M6 x 10 -
17 1 SuperVario cover plate RAL 5021 81397
18 2 Star grip nut 40 M6 A2 73216
19 1 Slide motor for SuperVario, incl. cable 81448
20 1 Stirring shaft ISO 13337 - 3 x 50 -
21 1 Double spherical bearings, black 73213
22 1 Blank edge guard, short, with padding 80259
23 1 Blank edge guard, long, with padding 80259
24 1 Blank edge guard without padding 80258
25 1 Shaft adapter for drive motor 82403
26 1 SuperVario drive motor 82402
27 1 Spacer ring for drive motor 82406
28 3 Z-bracket holder for drive motor 82405
29 1 Hopper 110 l outlet 81076
30 1 Residual discharge cover, black 80393
31 1 Hopper cover, black 80107
32 4 Star grip screw 50 M8x14 A2 73214
33 1 SuperVario impact plate RAL 5021 81398
34 2 Handle, black PA 6 81994
35 1 SuperVario load-relief cover 81139
36 3 Washers for Z-bracket holder -
37 3 DIN 9021 - 5.3 with PA -
