The ComGate10 supports WLAN connections:
The ComGate10 supports following sensor types:
• Leica Total Stations (TPS)
• Leica GPS/GNSS Systems
• Leica Nivel200
• Geotechnical sensors in combination with Campbell Dataloggers
Ports:
• One RS232 serial port in order to connect the sensors
• One USB port in order to connect the sensors
• Two Ethernet ports:
– for the connection to the Internet by Ethernet cable
– for the connection of any other communication module
The Leica ComGate10 contains two coupling relays which can be switched digitally, for
example to connect warning devices like signal lamps or sirens. One of them can be
used to switch the instrument off and on automatically.
Accessory:
The antenna for the mobile Internet/WLAN connection can be purchased as an official
accessory.
2.2.2 Software Concept
Configuration The delivered ComGate10 is preconfigured.
Leica ComBox
Manager
The ComBox Manager software is required to configure the ComGate10. Use this
configuration tool to:
• Set the general settings of the ComGate10, for example name and type.
• Set the settings of the mobile provider, for example phone number, user name and
password.
• Set the DynDNS address on the wireless router.
• Set the port numbers and baud rates of diverse ports, for example ports COM1 to
COM2 or COM1 and USB.
Content of the Leica
M-Com USB card
Following elements can be found on the Leica M-Com ComBox/ComGate10 USB card:
• Software:
– Leica ComBox Manager
– Adobe Reader
• Manual
• TruStory
• Documentation
• Leica Website
Standard Frequencies [GHz] Bandwith [MHz] Net Data Rate
[MBit/s]
Range
Indoor/Outdoor [m]
802.11b 2.4 20 11 35/140
802.11g 2.4 20 54 38/140
802.11n 2.4 20 150 70/250
