Leica ComGate10, Operation
33
3.7 LED Indicators on ComGate10
Description of the
LEDs
The ComGate10 has Light Emitting Diode indicators. They indicate the basic instru-
ment status.
LED LED Status Status of the instrument
Status LED The ComGate10 is busy due to startup, software
or configuration update.
The ComGate10 is ready.
Mobile LED The mobile connection is up.
• red: low quality connection
• yellow: medium quality connection
• green: best quality connection
The mobile connection is being established.
The mobile connection is down.
VPN LED VPN connection is up.
VPN connection is down.
USB LED USB connection to ComGate10 is set up.
Nothing is connected to the ComGate10 or TPS
is switched off.
WLAN LED WLAN connection is up.
• red: low quality connection
• yellow: medium quality connection
• green: best quality connection
WLAN connection is being established.
WLAN connection is down.
