Leica ComGate10 - Interfaces

Leica ComGate10, Technical Data
36
Dimensions
Weight 450 g
5.2 Interfaces
Ports
Width [mm] Height [mm] Depth [mm]
45 125 110
124.2 mm
~134.2 mm
45 mm
110 mm
~127.5 mm
006230_002
Port Panel Description
Front USB 2.0 host port.
Can be used as USB device server or for software/
configuration updates.
Front Ethernet port.
To connect the ComGate10 to another device, for
example WebCam or PC.
Can be used as LAN or WAN interface.
Front Ethernet port.
To connect the ComGate10 to the Internet.
Can be used as LAN or WAN interface.
Front SMA female connector for first LTE antenna.
Front SMA female connector for second LTE antenna.
Front SMA female connector for first WLAN antenna (main).
Front SMA female connector for second WLAN antenna
(diversity).
Mobile 1
Mobile 2
WLAN1
WLAN2
