Leica ComGate10, Operation
26
3.5 Mounting
Installation location • Install the ComGate10 preferably so, that it is protected from water, mechanical
influences, lightning and solar radiation.
• Install the mobile internet/WLAN antenna primarily outdoors, but also protected
from lightning.
During operation, the external antennas produce electromagnetic radiation.
Therefore they must be installed so that the minimal distance of 0.4 m to the
operator is adhered. To avoid legal restrictions regarding co-location of
antennas, the separation distance between the antennas must be 0.2 m
(shortest distance between the antenna surfaces).
• The meteo sensor should be mounted downwards in a dry area and protected from
solar radiation.
Installation orienta-
tion
It is recommended to install the antenna upwards.
Mounting • The ComGate10 should be fastened with the embedded DIN rail mounting.
• The mobile internet/WLAN antenna should be fastened in a vertical position with
the delivered screws and drill/plug anchors.
• Mounting installation for the antenna guide is delivered within the antenna box.
Cable installation Ensure that the cables between the sensors and the ComGate10 are positioned to
prevent them from becoming bent, stretched or squeezed.
3.6 Sensor Connection and Setups
DANGER
Electric Shock
Touching life components during installation or modification of the product, for
example in a host like an electrical cabinet, may cause you to receive an electric shock.
Precautions:
Always switch off the energy supply of the host before working at the product.Always
ensure that the working site is adequately secured. Adhere to the local regulations
governing safety and accident prevention.
WARNING
This product must be installed only by an appropriately trained and qualified specialist.
If the sensor and the ComGate10 are connected to the same power supply, then the
voltage used to power the ComGate10 must fulfil the sensor specification. Do not
connect higher voltage to the sensor than specified!
