Leica ComGate10, Technical Data
35
5 Technical Data
5.1 General Technical Data
Design Robust sheet steel housing with DIN rail mounting.
Supported products • MS60/TS60
• MS50/TM50/TS50
• TM30/TS30
• TS15
• TS16
• TPS1000/TPS1100/TPS1200
• GMX910
• GMX902
• Nivel210
• Nivel220
• DTM STS RS232 meteo sensors
• TP meteo sensor RS485
• Geotechnical Sensors in combination with Campbell Dataloggers.
• Warning devices, for example signal lamps or sirens. The ComGate10 contains two
coupling relays. Both coupling relays can be switched digitally to connect warning
devices.
One or two products can be connected to the ComGate10 in any combination.
Electrical data
Mobile interface
Environmental
specifications
The following precautions must be taken before installing a ComGate10 router:
• Avoid direct solar radiation
• Protect the device from humidity, steam and aggressive fluids
• Guarantee sufficient circulation of air around the device
• The device is for indoor use only
Type ComGate10
Voltage range 12–48 V DC (−15 %/+20 %)
Nominal voltage 12 V DC, 24 V DC, 36 V DC and 48 V DC
Current max. 0.42 A
Power consumption 5 W (no products are connected)
Type Mobile interface
ComGate10 GSM, GPRS, EDGE, UMTS, HSDPA, HSUPA and LTE
Operating temperature [°C] Storage temperature [°C]
−25 to +70 −25 to +70
External influences Protection
Water, dust and sand IP40 (IEC60529)
Protected against objects with a diameter bigger
than 1 mm. Not protected against water.
Humidity Up to 95 % (non condensing)
