11. Technical Description
Color-coding of the objectives
In accordance with DIN/ISO standards, the mag-
nification of each objective is indicated by a col-
or ring along the outer edge.
Immersion objectives are also marked by a sec-
ond, lower color ring:
Black Oil or Imm (= universal objective
for oil, water, glycerin)
White Water
Orange Glycerin
Performance data of the eyepieces
The following eyepieces are in the product line
for the Leica DMi1:
Leica eyepiece type Magnification/ Characteristics
+)
Field number
HC PLAN 10x/20 M
HC PLAN 10x/20
HC PLAN 12.5x/16 M
HC PLAN 10x/20 MF
Eyepiece tube diameter: 30mm
+)
= With removable or invertible protection screen for
eyeglass wearers and non-eyeglass wearers
M = Adjustable eyelens (dioptric equalization) and fixture
for graticules with diameter of 19mm or 26mm for
HC eyepieces.
MF = With illuminated graticule
100x
125x
150x
160x
63x 40x
50x
25x
32x
16x
20x
10x 6.3x 4x
5x
2.5x 1.6x
white dark
blue
light
blue
dark
green
bright
green
yellow orange red brown gray
