Leica FlexLine - Page 13

Peg Survey FlexLine/FlexLine plus, 13
1
a) I Set
2
a) I Set
b) II Set
)
The user must complete the number of sets as preset in
the tolerance settings. A maximum number of 20 sets is
supported by the application.
Sequence Displays the measuring sequence.
B’F’F’’B’’ Backsight-Foresight-Foresight-Backsight.
B’F’B’’F’ Backsight-Foresight-Backsight-Foresight.
B’B’’F’F’’ Backsight-Backsight-Foresight-Foresight.
Hz Tol Tolerated residual in horizontal direction.
HD Tol Tolerated residual in horizontal distance.
H Tol Tolerated residual in height.
Field Description
P1 P2
TSOX_Mining_002
a
P1 P2
TSOX_Mining_003
b
a
