38
Version 2.0, Revision I
Instrument Setup
4
1
5
3
2
6
4
1
Fig. 29
• When filling a magazine with cassettes, ensure that the cassette side to be imprinted is to the left
after insertion.
• If cassettes are individually loaded, be certain that they are aligned properly and that there are no
gaps between the cassettes.
• To achieve this, use your finger to carefully lift the cassettes slightly from below, then release them.
The cassettes should then lie in the magazine properly (→ "Fig. 30").
Fig. 30
