56
Instruction manual V3.2 – 02/2002
12. Optional accessories
Fig. 56.1
8
15
Fig. 56.2
13
14
14
Fuse replacement
Prior to replacing the fuses, turn the illumina-
tion off with the mains switch (8) and discon-
nect the carrier from the mains power supply!
The fuses are located in the voltage selector housing
(3).
• Place the tip of a small screw driver into the small
recess of the cover and push carefully to remove.
• Pull out the voltage selector housing (13).
• Remove the fuses (14).
Use fuses of the same specification only!
For correct fuse type, see label on the carrier.
• Mount new fuses of the same technical specifica-
tion.
The actual voltage setting can be seen in the small
window (15) of the voltage selector housing.
• Insert the voltage selector housing with the fuses
into the instrument, lightly push until it locks in place.
• Check if the correct voltage is indicated in window
(15).
• Reconnect the mains plug.
• Turn on with the mains switch.
