Leica TPS1200+ - Icon Meanings

User Interface TPS1200+ 45
2.4 Icons
Description The screen icons display the current status information of the instrument.
Position of the
icons on the screen
a) ATR/LOCK/PS
b) Reflector
c) EDM
d) Compensator/face I&II
e) RCS
f) Bluetooth
g) Line/area
h) CompactFlash card/internal memory
i) Battery
j) SHIFT
k) Quick coding
j
a
TPS12_172
b c d e f g h i
k
