Operation TPS1200+ 59
3.3.2 LED Indicators on SmartAntenna
LED Indicators Description
SmartAntenna has Light Emitting Diode indicators. They indicate the basic antenna
status.
Diagram of LED Indicators
TRK Tracking LED
BT Bluetooth LED
PWR Power LED
TPS12_200
TRK
BT
PWR
TRK
BT
PWR
ON
OFF
