Operation TPS1200+ 77
3.5.3 SmartAntenna Battery
Change battery
step-by-step
Step Description
Turn SmartAntenna over to gain access to the battery compartment.
1. Open the battery compartment by pushing the slide fastener in the direc-
tion of the arrow with the open-lock symbol.
2. Pull out the battery housing. The battery is attached to the housing.
3. Hold the battery housing and pull the battery from the battery housing.
1
2
TPS12_193
3
4
