Operation TPS1200+ 71
3.4.2 LED Indicators on RadioHandle
LED Indicators Description
The RadioHandle has Light Emitting Diode indicators. They indicate the basic
RadioHandle status.
Diagram of the LED Indicators
a) Power LED
b) Link LED
c) Data Transfer LED
d) Mode LED
abc d
