User Interface TPS1200+ 49
CompactFlash
card/internal memory
The status of the CompactFlash card and internal
memory if fitted are displayed.
• For the CompactFlash card, the capacity of used
space is shown in seven levels.
• For the internal memory if fitted, the capacity of used
memory is shown in nine levels.
Battery The status and source of the battery is displayed. The
percentage of remaining power capacity for all batteries
are displayed numerically and graphically. For internal
and external battery being attached at the same time the
internal battery is used until it is empty and then the
external battery is used.
SHIFT The status of the SHIFT key is displayed.
Quick coding Shows the quick coding configuration. Can be used with
touch screen to turn quick coding on and off.
Icon Description
