56TPS1200+
Operation
Step Description
1. A circular screw is located at one end of the clip-on-housing. Ensure that
the circular screw is in the unlocked position. Turn it anticlockwise, as
shown by the lock and arrow symbols on the screw.
2. Slide the clip-on-housing into position underneath the SmartAntenna
Adapter, such that the guide rails on the clip-on-housing and the guide
rails on the SmartAntenna Adapter are aligned.
Ensure that the connector located at the end of the clip-on-housing fits into
its port of the SmartAntenna Adapter.
3. Lock the circular screw by turning it clockwise, as shown by the lock and
arrow symbols on the screw. The clip-on-housing is now locked into posi-
tion.
4. Thread the antenna onto the clip-on-housing.
