59
BOX JOINTS
Chapter 14Super Jig-12-18-24 User Guide
14-1 Bit and Guidebush selection Only the e7-Bush and
5
⁄16" bit that came with Superjig
are required for all Superjig
box joints. Note: Spiral upcut router bits
will cut cleaner than
straight flute. Where metric size bits are available an 8mm straight
or spiral bit may be substituted for the
5
⁄16". Always start test
routing with the e7-Bush set on “5”, the adjustment mid-range.
5
1 21
14-2
5
⁄16"[8mm] Box Joints.
Place the finger assembly on the support brackets in the HB TAILS
mode, set the scales on the small triangular arrow
and lower
the assembly onto the spacer board.
1
1
14-3 Clamp a test board in the front left clamp, against the side
stop with the top edge flush under the guidefingers. The board
may be clamped face side in or out
j
. Mark and adjust the depth
of cut to suit the thickness of the mating boards
.
14-4 Raise the finger assembly about
1
⁄16"[2mm] to allow ease
of guide finger adjustment
. Position the second guidefinger
1
⁄32"[1,0mm] in from the board edge
and tighten the finger.
The first finger stays against the scale block as a router support
.
Note: Square ended boards are essential to achieve flush joint alignment.
1
2
3
14-5 Place the Spacer on the finger bar to the right of the second
finger, numeral 1 on top overlapping the locked finger
. Move
the next finger in to touch the Spacer
. Hold the guidefinger
firmly against the Spacer and tighten the second finger screw
.
As you remove the Spacer you should feel some friction; this
indicates that the guidefinger is correctly spaced
➃
.
1
2
3
4
14-6 Repeat this procedure across the jig until there is at least
one guidefinger spaced past the right side of the work piece
.
Tighten the unused guides. Store the Spacer on the outside of a
rear side stop
.
1
2
