Page 2
Unit Dimensions − inches (mm)
CORNER WEIGHTS  lbs. (kg)
Model
AA BB CC DD
Model
Number
lbs. kg lbs. kg lbs. kg lbs. kg
12CHP024 77 35 56 25 61 28 82 37
12CHP030 86 39 63 29 69 31 92 42
12CHP036 117 53 85 39 93 42 125 57
12CHP042 118 54 86 39 94 43 126 57
12CHP048 121 55 88 40 96 44 129 59
12CHP060 127 57 92 42 101 46 135 61
CENTER OF GRAVITY  inches (mm)
Model
EE FF
Model
Number
inch mm inch mm
12CHP024 217/8 556 261/2 673
12CHP030 217/8 556 261/2 673
12CHP036 233/4 603 311/4 794
12CHP042 233/4 603 311/4 794
12CHP048 233/4 603 311/4 794
12CHP060 23−3/4 603 31−1/4 794
OUTDOOR COIL
EXHAUST AIR
FRONT VIEW
TOP VIEW
TOP VIEW BASE SECTION
BACK VIEW
LEFT SIDE
OUTDOOR
COIL
INTAKE
AIR
CONDENSATE
DRAIN
COMPRESSOR
DOWNFLOW
SUPPLY AIR
OPENING
OUTDOOR
COIL FAN
DOWNFLOW
RETURN AIR
OPENING
HORIZONTAL
SUPPLY AIR
OPENING
HORIZONTAL
RETURN AIR
OPENING
AA
D
BB
CC
DD
CONDENSER COIL
INTAKE AIR
OUTDOOR
COIL
OUTDOOR COIL
EXHAUST AIR
A
C
B
B
RIGHT SIDE
BLOWER
C
HORIZONTAL
RETURN AIR
OPENING
(048/060)
A
LE
F
GG
2 (51)
FF
EE
FILTER
RACK
BASE RAIL
27/16
(62)
45/8
(117)
CENTER
OF
GRAVITY
K
KK
K
J
JJ
J
E
H
N
FORKLIFT
SLOTS
(Front and
Back Only)
BASE RAIL
BASE RAIL
P
M
BASE RAIL
BASE RAIL
INDOOR
COIL
BLOWER
OPTIONAL
ELECTRIC
HEAT
(Field
Installed)
ELECTRICAL
INLETS
OPTIONAL
ELECTRIC HEAT
(Field Installed)
ELECTRIC
HEAT
POWER INLET
REFRIGERANT
SERVICE
PORTS
Model
A B C D E F G
Model
Number
inch mm inch mm inch mm inch mm inch mm inch mm inch mm
−024 2711/16 703 455/8 1159 455/8 1159 251/4 641 113/16 46 4 102 17/8 48
−030 3111/16 805 455/8 1159 455/8 1159 291/4 743 113/16 46 4 102 17/8 48
−036, −042, −048, −060 3311/16 856 5411/16 1389 495/8 1260 317/16 799 11/8 29 61/4 159 21/4 57
Model
H J K L M N P
Model
Number
inch mm inch mm inch mm inch mm inch mm inch mm inch mm
−024 155/8 397 111/2 292 171/2 445 4 102 5 127 463/8 1179 463/8 1179
−030 155/8 397 111/2 292 171/2 445 4 102 5 127 463/8 1179 463/8 1179
−036, −042, −048, −060 171/8 435 12 305 211/2 546 55/8 143 41/8 105 551/4 1403 501/2 1283
