CLIMATIC™50 – IOM – Rooftops/ Aircoolair CL50-ROOFTOPS-IOM-1107-E
25
CUSTOMIZED INPUT/OUTPUT
Function
On the BM.50 card and with the optional expansion board BE.50, it is possible to customize some input / output for
remote control of the unit. So it is possible to customize
• 5 digital outputs NC or NO set up with parameters 3841, 3842, 3843 and 3845
• 6 digitals inputs set up by parameters 3851, 3852, 3853 and 3854
• 4 analogical inputs (4-20mA or Lennox NTC temperature probe), set up with parameters 3861, 3862, 3863 et 3864
Description
Il est possible de paramétrer les fonctions suivantes :
SORTIE DIGITALE NC ou NO - CONTACTS SECS
Following information could be recovered from each contact :
[Not Used.] No contact
[Filter Al
.] Filter fault
[Blower Al
.] Blowing fan fault
[Comp. Al.] Compressor fault
[Gas Al] Gaz fault
[ElecH. Al] Electrical heater fault
[Frost. Al] Alarm, freezing risk
[Smoke. Al.] Smoke detector alarm
[Heat. Mode] Heating mode
[Humidif.] Humidifier pilote
[Z:A] Unit operating Mode A
[Z:B] Unit operating Mode B
[Z:C] Unit operating Mode C
[Uno] Unit operating Mode Inoccupied
[Bms] Unit operating Mode BMS
[LibrFree] Free for BMS acting
[Exhaust 1] Drive exhaust fan n°1
[Exhaust 2] Drive exhaust fan n°2
[Exhaust 3] Drive exhaust fan n°3
3841 ! Setting of connector BM50-J17-N12.
3842 ! Setting of connector BE50-J5-N1.
3843 ! Setting of connector BE50-J6-N2.
3844 ! Setting of connector BE50-J7-N3.
3845 ! Setting of connector BE50-J8-N4.
ENTREE DIGITALE 24V AC ou DC
following orders can be sent on each contact:
[Not Used] No contact
[Sw Unoc.] Force Unoccupied Mode
[Dis. Cp/AH] Stop of all compressors and auxillary heating
[Dis. Comp. ] Stop of all compressors
[Dis. 50%Cp] Immediate stop of 50% of the compressors
[Dis. AuxH.] Stop of supplementary heating
[Sw Dis.Cool] Cancellation of cooling mode
[Sw Dis.Heat] Cancellation of heating mode
[State Humi] Humidifier fault input
[0% F.A. ] Force 0% fresh air
[10% F.A.] Add 10% fresh air
[20% F.A. ] Add 20% fresh air
[30% F.A.] Add 30% fresh air
[40% F.A.] Add 40% fresh air
[50% F.A.] Add 50% fresh air
[100% F.A.] Force 100% fresh air
[Low Speed] Force low speed ventilation
[Free] Free for BMS system information.
