CLIMATIC™50 – IOM – Rooftops/ Aircoolair CL50-ROOFTOPS-IOM-1107-E
8
CONFIGURATION
Function
LENNOX© proposes a single software for the whole ranges of Roof-Top and Aircooler.
For a first use, before any operation of the unit, Climatic™ must be set with parameters in accordance to the range, the size and
the various options of the unit.
Description
The unit configuration is done with following menus (refer also to Menu Tree chapter):
3811 ! Unit range choice
[BC] Baltic, cooling only
[BH] Baltic, reversible (heat pump)
[BG] Baltic, gas
[BD] Baltic, gas and reversible (heat pump)
[BGN] Baltic, gas, without compressor
[FC] Flexy 1, cooling only
[FC²] Flexy 2, cooling only
[FH] Flexy 1, reversible (heat pump)
[FH²] Flexy 2, reversible (heat pump)
[FG] Flexy 1, gas
[FG²] Flexy 2, gas
[FD] Flexy 1, gas and reversible (heat pump)
[FD²] Flexy 2, gas and reversible (heat pump)
[FGN] Flexy, gas, without compressor
[FW] Flexy, cool water coil, without compressor
[FX] Roof-Top with module 4 dampers
[ANC] Aircooler, cooling only
[ANH] Aircooler, reversible (heat pump
[NSR] Unit of nonstandard request
3812 ! Unit size choice
BC BH BG BD BGN FC FC² FH FH² FG FG² FD FD² FGN FWN FX ANC ANH
BCK020NS
BHK020NS
BGK020SS
BDK020SS
BGN001S FCK085N
FCM085N
FHK085N
FHM085N
FGK085S FGM085S FDK085S FDM085S FGN002S
FWN002S
FXK025N
ANCM022E ANHM022E
BCK025NS
BHK025NS
BGK025SS
BDK025SS
BGN001H
FCK100N
FCM100N
FHK100N
FHM100N
FGK100S FGM100S FDK100S FDM100S FGN003S
FWN003S
FXK030N
ANCM026E ANHM026E
BCK030NS
BHK030NS
BGK030SS
BDK030SS
FCK120N
FCM120N
FHK120N
FHM120N
FGK120S FGM120S FDK120S FDM120S FGN004S
FWN004S
FXK035N
ANCM032E ANHM032E
BCK035NS
BHK035NS
BGK035SS
BDK035SS
FCK140N
FCM150N
FHK140N
FHM150N
FGK140S FGM150S FDK140S FDM150S FGN005S
FWN005S
FXK040N
ANCM038E ANHM038E
BCK040NS
BHK040NS
BGK040SS
BDK040SS
FCK160N
FCM170N
FHK160N
FHM170N
FGK160S FGM170S FDK160S FDM170S
FGN002H
FWN002H
FXK055N
ANCM043E ANHM043E
BCK045NS
BHK045NS
BGK045SS
BDK045SS
FCK190N
FCM200N
FHK190N
FHM200N
FGK190S FGM200S FDK190S FDM200S
FGN003H
FWN003H
FXK070N
ANCM052D ANHM052D
BCK030ND
BHK030ND
BGK030SD
BDK030SD
FCM230N
FHM230N FGK085H
FGM230S FDK085H FDM230S
FGN004H
FWN004H
FXK085N
ANCM064D ANHM064D
BCK035ND
BHK035ND
BGK035SD
BDK035SD
FGK100H FGM085H
FDK100H
FDM085H FGN005H
FWN005H
FXK100N
ANCM076D ANHM076D
BCK040ND
BHK040ND
BGK040SD
BDK040SD
FGK120H FGM100H
FDK120H
FDM100H
FXK110N
ANCM086D ANHM086D
BCK045ND
BHK045ND
BGK045SD
BDK045SD
FGK140H FGM120H
FDK140H
FDM120H
FXK140N
ANCM112D ANHM112D
BCK050ND
BHK050ND
BGK050SD
BDK050SD
FGK160H FGM150H
FDK160H
FDM150H
FXK170N
ANCM128D ANHM128D
BCK060ND
BHK060ND
BGK060SD
BDK060SD
FGK190H FGM170H
FDK190H
FDM170H
ANCM152D ANHM152D
BCK070ND
BHK070ND
BGK070SD
BDK070SD
FGM200H
FDM200H
BHK020HS
BGK020HS
BDK020HS
FGM230H
FDM230H
BHK025HS
BGK025HS
BDK025HS
BHK030HS
BGK030HS
BDK030HS
BHK035HS
BGK035HS
BDK035HS
BHK040HS
BGK040HS
BDK040HS
BHK045HS
BGK045HS
BDK045HS
BHK030HD
BGK035HD
BDK030HD
BHK035HD
BGK040HD
BDK035HD
BHK040HD
BGK045HD
BDK040HD
BHK045HD
BGK050HD
BDK045HD
BHK050HD
BGK060HD
BDK050HD
BHK060HD
BGK030HD
BDK060HD
BHK070HD
BGK070HD
BDK070HD
3813 ! Activation of the Controls humidity option
3814 ! Activation of the High Efficiency Main fan and/or Variable speed transmission option,
3815 ! Activation of the External Thermostat Temperature Control option,
3821 ! Choice of the type of sensor or probe on the refrigeration circuit
[No] No probe or sensor of installed on the circuits
