CLIMATIC™50 – IOM – Rooftops/ Aircoolair CL50-ROOFTOPS-IOM-1107-E
70
BMS Adress Tables ModBus, LonWorks
MODBUS
Logical
@ (hexa) @ (deci) DS50
01H 1
R/W L [On / Off] Unit
3111
02H 2
R/W L [Reset] Discharges the safety measures of the unit
3112
03H 3
R/W L
[Enable] Stopping and running of the Fan Blower.[Off] the blower is stopped, [On]
the blower is running.
3351
(BMS)
04H 4
R/W L
[Enable] Stopping and running of the fan in the "Control Dead Zone". [Off] the
blower is stopped, [On] the blower is running.
3352
(BMS)
05H 5
R/W L
[BMS] Activation of the Inoccupation mode [Off] occupation mode - [On]
inoccupation mode
3935
06H 6
R/W L
[Room regulation] Choices of the priority of regulation in Heating - [Off] Heat Pump
then Hot water coil or Electric or Gas [On] Hot water coil or Electric or Gas then
Heat Pump
3324
(BMS)
07H 7
R/W L
[F-Air Reheat] Activate reheating of the fresh air in the dead zone to maintain
supply temperature.
3331
(BMS)
08H 8
R/W L
[F-Air Reheat] Choices of the priority of regulation in Heating - [Off] Heat Pump
then Hot water coil or Electric or Gas [On] Hot water coil or Electric or Gas then
Heat Pump
3332
(BMS)
09H 9
R/W L [Enable] Run eco: [On] the Economiser is running, [Off] the Economiser if stopped.
3353
(BMS)
0AH 10
R/W L
[Enable] Run CO2 Sensor: [On] Switch-on the CO2 control on a Zone, [Off] Stop
the CO2 control on a zone.
3354
(BMS)
0BH 11
R/W L [Enable] [OFF] Force the unloading of compressors in cooling mode.
3355
(BMS)
0CH 12
R/W L [Enable] [OFF] Force the unloading of compressors in heating mode.
3356
(BMS)
0DH 13
R/W L
[Enable] [OFF] Force the unloading of heating module (electric, gas or heat water
coil)
3357
(BMS)
0EH 14
R/W L [Enable] [OFF] Force the unloading of humidity control.
3358
(BMS)
0FH 15
R/W L
[Unloaded] Force the stop of half of the compressors moving has the moment of
the activation of this point.
3643
10H 16
R/W L [Clock] [OFF] read hour & minute [ON] write hour & minute
…
11H 17
R/W L [Dry contact] Digital Output, Free 1, BM50-J17-NO12
2141
12H 18
R/W L [Dry contact] Digital Output, Free 2, BE50-J5-NO1
2142
13H 19
R/W L [Dry contact] Digital Output, Free 3, BE50-J6-NO2
2143
14H 20
R/W L [Dry contact] Digital Output, Free 4, BE50-J7-NO3
2144
15H 21
R/W L [Dry contact] Digital Output, Free 5, BE50-J8-NO4
2145
16H 22
R/W L
not used
17H 23
R/W L
not used
18H 24
R/W L
not used
19H 25
R/W L
not used
1AH 26
R/W L
not used
1BH 27
R/W L
not used
1CH 28
R/W L
not used
1DH 29
R/W L
not used
1EH 30
R/W L
not used
1FH 31
R/W L
not used
To Next Page
