Lennox CL50-RoofTop - Page 73

71
CLIMATIC™50 – IOM – Rooftops/ Aircoolair CL50-ROOFTOPS-IOM-1107-E
71
@ (hexa) @ (deci) DS50
20H 32
R/W L
not used
21H 33
R L [Alarm] General
1000
22H 34
R L [On/Off] Fan, Blower
2315
23H 35
R L [On/Off] Fan, Extraction
2321
24H 36
R L [On/Off] Compressor, 1
2516
25H 37
R L [On/Off] Compressor, Heat pump, 1
2517
26H 38
R L [On/Off] Compressor, 2
2526
27H 39
R L [On/Off] Compressor, Heat pump, 2
2527
28H 40
R L [On/Off] Compressor, 3
2536
29H 41
R L [On/Off] Compressor, Heat pump, 3
2537
2AH 42
R L [On/Off] Compressor, 4
2546
2BH 43
R L [On/Off] Compressor, Heat pump, 4
2547
2CH 44
R L [On/Off] Gas, Burner, 1
2615
2DH 45
R L [On/Off] Gas, Burner, 2
2616
2EH 46
R L [On/Off] Gas, Burner, High power, 1
2617
2FH 47
R L [On/Off] Electrical heaters, 1
2625
30H 48
R L [On/Off] Electrical heaters, 2
2626
31H 49
R L [Dry contact] Digital Input, Free 1, BM50-J8-ID13
2151
32H 50
R L [Dry contact] Digital Input, Free 2, BM50-J8-ID14
2152
33H 51
R L [Dry contact] Digital Input, Free 3, BE50-J4-ID1
2153
34H 52
R L [Dry contact] Digital Input, Free 4, BE50-J4-ID2
2154
35H 53
R L [Dry contact] Digital Input, Free 5, BE50-J4-ID3
2155
36H 54
R L [Dry contact] Digital Input, Free 6, BE50-J4-ID4
2156
37H 55
R L
not used
38H 56
R L
not used
39H 57
R L
not used
3AH 58
R L
not used
3BH 59
R L
not used
3CH 60
R L
not used
3DH 61
R L
not used
3EH 62
R L [Room] Cool Mode
…
3FH 63
R L [Room] Deadz one Mode
…
40H 64
R L [Room] Heat Mode
…
Analogical
@ (hexa) @ (deci) DS50
01H 1
R/W 1 = 1 s
[ BMS ] Activation of the control by a computer or an automat - mode
BMS is activated if this value is different from zero, This value is
decreased every second
3934
02H 2
R/W 10 = 1.0°c
[Occupation][Room SP] Required maximum room temperature in °C.
Cooling set point
3322
(BMS)
03H 3
R/W 10 = 1.0°c
[Occupation][Room SP] Required minimum room temperature in °C.
Heating set point
3323
(BMS)
04H 4
R/W 1 = 1%
[Room SP] Required room minimum fresh air rate in % Middle of the
dead zone.
3312
(BMS)
05H 5
R/W 10 = 1.0°c
[Inoccupation][Room SP] Required maximum room temperature in °C.
Cooling set point
3322
(Uno)
