CLIMATIC™50 – IOM – Rooftops/ Aircoolair CL50-ROOFTOPS-IOM-1107-E
72
@ (hexa) @ (deci) DS50
06H 6
R/W 10 = 1.0°c
[Inoccupation][Room SP] Required minimum room temperature in °C.
Heating set point
3323
(Uno)
07H 7
R/W 1 = 1%
[Humidity] Desired Maximum relative humidity in Room (in %). –
Dehumidification set point.
3341
(BMS)
08H 8
R/W 1 = 1%
[Humidity] Desired Minimum relative humidity in Room (in %). –
Humidification set point.
3342
(BMS)
09H 9
R/W
not used
0AH 10
R/W
not used
0BH 11
R/W
not used
0CH 12
R/W 1 = 1h [Clock] Hour
3121
0DH 13
R/W 1 = 1m [Clock] Minute
3122
0EH 14
R/W 1 = 1 [Clock] Day of the month
3123
0FH 15
R/W 1 = 1 [Clock] Month
3124
10H 16
R/W 1 = 2001 [Clock] Year
3125
11H 17
R/W 10 = 1.0°c [BMS] Room temperature coming from the BMS
2824
12H 18
R/W 10 = 1.0% [BMS] Room humidity coming from the BMS
2828
13H 19
R/W 10 = 1.0°c [BMS] Outdoor temperature coming from the BMS
2814
14H 20
R/W 10 = 1.0% [BMS] Outdoor humidity coming from the BMS
2818
15H 21
R/W 1 = 1 ppm
[BMS] Air quality coming from the BMS
16H 22
R/W
not used
17H 23
R/W
not used
18H 24
R/W
not used
19H 25
R/W
not used
1AH 26
R/W
not used
1BH 27
R/W
not used
1CH 28
R/W
not used
1DH 29
R/W
not used
1EH 30
R/W
not used
1FH 31
R/W
not used
20H 32
R/W
not used
21H 33
R 1 = 1 [Alarm] Code Error
1000
22H 34
R 10 = 1.0°c [Temperature] Room
2112
23H 35
R 10 = 1.0°c [Temperature] Outdoor
2111
24H 36
R 10 = 1.0°c [Temperature] Supply
2113
25H 37
R 10 = 1.0°c [Temperature] Return
2114
26H 38
R 10 = 1.0% [Relative Humidity] Room
2122
27H 39
R
10 = 1.0
g/Kg
[Absolute Humidity] Room
2124
28H 40
R 10 = 1.0% [Relative Humidity] Outdoor
2121
29H 41
R
10 = 1.0
g/Kg
[Absolute Humidity] Outdoor
2123
2AH 42
R 1 = 1 pa [Flow] Differential pressure on the air, in pascal
2131
2BH 43
R 1 = 1 ppm [CO²] Level in ppm
2132
2CH 44
R 1 = 1% [% of opening] Register of fresh air
2413
2DH 45
R 1 = 1% [% of opening] Valve gas
2618
2EH 46
R 1 = 1% [% of opening] Electrical heaters (Triac)
2627
2FH 47
R 1 = 1% [% of opening] Hot water coil
2633
