73
CLIMATIC™50 – IOM – Rooftops/ Aircoolair CL50-ROOFTOPS-IOM-1107-E
73
@ (hexa) @ (deci) DS50
30H 48
R 1 = 1% [% of opening] Humidifier
2714
31H 49
R 10 = 1.0°c [Dry contact] Temperature, Free 1, BE50-J9-B1
2161
32H 50
R 10 = 1.0°c [Dry contact] Temperature, Free 2, BE50-J9-B2
2162
33H 51
R 10 = 1.0°c [Dry contact] Temperature, Free 3, BE50-J10-B3
2163
34H 52
R 10 = 1.0°c [Dry contact] Temperature, Free 4, BE50-J10-B4
2164
35H 53
R 10 = 1.0% [Dry contact] Humidity, Free 1, BE50-J9-B1
2165
36H 54
R 10 = 1.0% [Dry contact] Humidity, Free 2, BE50-J9-B2
2166
37H 55
R 10 = 1.0% [Dry contact] Humidity, Free 3, BE50-J10-B3
2167
38H 56
R 10 = 1.0% [Dry contact] Humidity, Free 4, BE50-J10-B4
2168
39H 57
R 1 = 1 h [Running Time, Count] Fan, Blower
2318
3AH 58
R 1 = 1 h [Running Time, Count] Compressor, 1
2519
3BH 59
R 1 = 1 h [Running Time, Count] Compressor, 2
2529
3CH 60
R 1 = 1 h [Running Time, Count] Compressor, 3
2539
3DH 61
R 1 = 1 h [Running Time, Count] Compressor, 4
2549
3EH 62
R bit
[Alarm]
bit.0 = Air Flow
bit.1 = Dirty Filters
bit.2 = No Filters
bit.3 = Electrical heaters
bit.4 = High Temperature, Supply
bit.5 = Low Temperature, Room
bit.6 = Gas Burner 1
bit.7 = Gas Burner 2
bit.8 = Low Temperature, Supply
bit.9 = High Temperature, Room
bit.10 = Humidifier
bit.11 = Low Humidity, Room
bit.12 = High Humidity, Room
bit.13 = Pump
bit.14 = Real Time Clock
bit.15 = BE50
…
3FH 63
R bit
[Alarm]
bit.0 = Probes & Sensors
bit.1 = Fan, Blower
bit.2 = Low Temperature, Condenser Water
bit.3 = High Temperature, Condenser Water
bit.4 = Flow Switch, Condenser Water
bit.5 = Smoke Detector
bit.6 = Fans, Condenser
bit.7 = Compressor 1, H.P. & I.P.
bit.8 = Compressor 1, L.P.
bit.9 = Compressor 2, H.P. & I.P.
bit.10 = Compressor 2, L.P.
bit.11 = Compressor 3, H.P. & I.P.
bit.12 = Compressor 3, L.P.
bit.13 = Compressor 4, H.P. & I.P.
bit.14 = Compressor 4, L.P.
bit.15 =
…
40H 64
R
not used
