BMS address table for LonWorks
Type Index pCO Name NV Type NV Direction Index pCO DS50
ANL 1 I_Sp_T_Cool_BMS 105 input 1
ANL 1 O_Sp_T_Cool_BMS 105 output 1
[Occupation][Room SP] Required maximum room
temperature in °C. Cooling set point
3322
(BMS)
ANL 2 I_Sp_T_Heat_BMS 105 input 2
ANL 2 O_Sp_T_Heat_BMS 105 output 2
[Occupation][Room SP] Required minimum room
temperature in °C. Heating set point
3323
(BMS)
ANL 3 I_Sp_T_Cool_Uno 105 input 3
ANL 3 O_Sp_T_Cool_Uno 105 output 3
[Inoccupation][Room SP] Required maximum room
temperature in °C. Cooling set point
3322
(Uno)
ANL 4 I_Sp_T_Heat_Uno 105 input 4
ANL 4 O_Sp_T_Heat_Uno 105 output 4
[Inoccupation][Room SP] Required minimum room
temperature in °C. Heating set point
3323
(Uno)
ANL 5 I_Sp_Hr_Dehu_BMS 81 input 5
ANL 5 O_Sp_Hr_Dehu_BMS 81 output 5
[Humidity] Desired Maximum relative humidity in
Room (in %). – Dehumidification set point.
3341
(BMS)
ANL 6 I_Sp_Hr_Humi_BMS 81 input 6
ANL 6 O_Sp_Hr_Humi_BMS 81 output 6
[Humidity] Desired Minimum relative humidity in
Room (in %). – Humidification set point.
3342
(BMS)
ANL 17 O_T_Room 105 output 17 [Temperature] Room 2112
ANL 18 O_T_Outside 105 output 18 [Temperature] Outdoor 2111
ANL 19 O_Ia_T_Supply 105 output 19 [Temperature] Supply 2113
ANL 20 O_Hr_Room 81 output 20 [Relative Humidity] Room 2122
ANL 21 O_Ha_Room 23 output 21 [Absolute Humidity] Room 2124
ANL 22 O_Hr_Outside 81 output 22 [Relative Humidity] Outdoor 2121
ANL 23 O_Ha_Outside 23 output 23 [Absolute Humidity] Outdoor 2123
INT 1 I_Sp_BMS_Dog 8 input 208
INT 1 O_Sp_BMS_Dog 8 output 208
[ BMS ] Activation of the control by a computer or
an automat - mode BMS is activated if this value is
different from zero, This value is decreased every
second
3932
INT 2 I_Sp_EcoMini_BMS 8 input 209
INT 2 O_Sp_EcoMini_BMS 8 output 209
[Room SP] Required room minimum fresh air rate
in % Middle of the dead zone.
3312
(BMS)
INT 3 I_Hour 8 input 210
INT 3 O_Hour 8 output 210
[Clock] Hour 3121
INT 4 I_Minute 8 input 211
INT 4 O_Minute 8 output 211
[Clock] Minute 3122
INT 5 I_Day 8 input 212
INT 5 O_Day 8 output 212
[Clock] Day of the month 3123
INT 6 I_Month 8 input 213
INT 6 O_Month 8 output 213
[Clock] Month 3124
INT 17 O_Error_Codes 8 output 224 [Alarm] Code Error 1000
INT 18 O_Oa_Eco 81 output 225 [% of opening] Register of fresh air 2413
INT 19 O_Oa_GasHeat 81 output 226 [% of opening] Valve gas 2618
INT 20 O_Oa_TriacHeat 81 output 227 [% of opening] Electrical heaters (Triac) 2627
INT 21 O_Oa_HotWater 81 output 228 [% of opening] Hot water coil 2633
DGT 1 I_Sp_On_Unit 95 input 415
DGT 1 O_Sp_On_Unit 95 output 415
[On / Off] Unit 3111
DGT 2 I_Sp_Reset 95 input 416
DGT 2 O_Sp_Reset 95 output 416
[Reset] Discharges the safety measures of the unit 3112
DGT 3 I_Sp_Unoc 95 input 417
DGT 3 O_Sp_Unoc 95 output 417
[BMS] Activation of the Inoccupation mode [Off]
occupation mode - [On] inoccupation mode
3933
DGT 4 I_Clock 95 input 418
[Clock] [OFF] read hour & minute [ON] write hour &
minute
…
DGT 17 O_Od_Alarm 95 output 431 [Alarm] General 1000
DGT 18 O_Od_Blower 95 output 432 [On/Off] Fan, Blower 2315
DGT 19 O_Od_Comp_1 95 output 433 [On/Off] Compressor, 1 2516
DGT 20 O_Od_CPac_1 95 output 434 [On/Off] Compressor, Heat pump, 1 2517
DGT 21 O_Od_Comp_2 95 output 435 [On/Off] Compressor, 2 2526
DGT 22 O_Od_CPac_2 95 output 436 [On/Off] Compressor, Heat pump, 2 2527
DGT 23 O_Od_Comp_3 95 output 437 [On/Off] Compressor, 3 2536
