CLIMATIC™50 – IOM – Rooftops/ Aircoolair CL50-ROOFTOPS-IOM-1107-E
65
Menu Item Menu Item Menu Item Menu Item Unité Mini. Usine Maxi.
3732 Opening % 0 0 50
3733 A.Freeze Lst_Afre 0 1 1
3740 Pump 3741 Mode Lst_Pump 0 0 3
3800 Config. 3810 Unit 3811 Range Lst_Rang 0 6 13
3812 Size Lst_Size 0 0 162
3813 Hu. Pack No/Yes ~ No ~
3814 h.e. No/Yes ~ No ~
3815 Tcb No/Yes ~ No ~
3820 Compressor 3821 Sensor Lst_Sens 0 0 3
3822 Lak No/Yes ~ No ~
3823 Wat/Cond No/Yes ~ No ~
3824 085/100 + No/Yes ~ No ~
3830 Option 3831 AuxHeat Lst_AuxH 0 0 8
3832 F.Air Lst_Eco 0 0 3
3833 P. Air Lst_FAir 0 0 2
3834 Co2 Lst_CO2C 0 0 2
3840
Out.
Custom.
3841 bm50.1 Lst_DO 0 0 15
3842 be50.1 Lst_DO 0 0 15
3843 be50.2 Lst_DO 0 0 15
3844 be50.3 Lst_DO 0 0 15
3845 be50.4 Lst_DO 0 0 15
3850 In. Custom. 3851 bm50.1 Lst_DI 0 0 17
3852 bm50.2 Lst_DI 0 0 17
3853 be50.1 Lst_DI 0 0 17
3854 be50.2 Lst_DI 0 0 17
3855 be50.3 Lst_DI 0 0 17
3856 be50.4 Lst_DI 0 0 17
3860
In.%
Custom.
3861 be50.1 Lst_AI 0 0 6
3862 be50.2 Lst_AI 0 0 6
3863 be50.3 Lst_AI 0 0 6
3864 be50.4 Lst_AI 0 0 6
3900 Com. 3910 Display 3911 Sp Mini. °c 8 17 21
3912 Sp Maxi. °c 21 27 35
3913 Offset °c -5 0 5
3914 Standard Sp No/Yes ~ No ~
3920 Master/Slave 3921 Id ~ 1 1 12
3922 Number ~ 1 1 12
3923 Type Lst_MS_1 0 0 4
3924 DC50 Mast. No/Yes ~ No ~
3925 Room Lst_MS_2 0 0 2
3926 Outside Lst_MS_2 0 0 2
3927 Co2 Lst_MS_2 0 0 2
3930 Bms 3931 Id ~ 1 1 199
3932 Type Lst_BMS 0 1 4
3933 Baud Lst_Baud 0 3 4
3934 Watchdog ~ 0 0 1000
3935 Bms Unoc. Off/On ~ Off ~
