NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
4. With both doors open, remove the four socket head cap screws,
two on each side, securing the top. Lift and remove the top of
the stove.
5. Unlatch main door and lift straight up off of the locating hinge
pins.
6. Reinstall door assembly following steps in reverse order.
Glass Door Cleaning and Maintenance
Cleaning: Do not remove or clean the glass door when hot. When
cool, the glass may be cleaned with a clean, soft cloth and glass cleaner.
For cleaning white condensation from the interior glass use a gas stove
glass cleaner available from your stove dealer. Use of caustic or abrasive
cleaners may damage glass. Gold or nickel plated trim must be cleaned
with glass cleaner or denatured alcohol and a soft cloth before firing
or fingerprints and stains will remain permanently. Never use abrasive
polish to clean the gold or nickel as it will ruin the finish. DO NOT spray
commercial glass cleaner with ammonia on the door and glass gasket
as it may dissolve the gasket glue.
Repair: If the glass is broken in the glass door, the entire door (metal
frame, gasket and glass) should be replaced as a unit. This replacement
glass door is available from your Lennox Hearth Products dealer. Do not
use substitute parts or materials. The glass is neo-ceramic and alternative
types must not be used.
NOTE: BE CAREFUL NOT TO SPRAY COMMERCIAL GLASS
CLEANER WITH AMMONIA ON GASKET AREA OF DOOR. AM-
MONIA WILL DISSOLVE GASKET GLUE.
NOTE: GOLD PLATED SURFACE MUST BE CLEANED WITH GLASS
CLEANER AND SOFT RAG BEFORE FIRING THE FIRST TIME OR
FINGER PRINTS AND STAINS WILL REMAIN PERMANENTLY.
NEVER USE BRASS POLISH TO CLEAN GOLD, THIS WILL RE-
MOVE GOLD PLATING!
Figure 35
Glass Door
Only doors certified with the appliance shall be used.
Seules des portes certifiées pour cet appareil doivent être
utilisées.
CAUTION: DO NOT abuse glass door by striking or slamming
shut.
Do not remove glass door while the appliance is hot.
Opening and Removing Door
To replace the door:
1. Shut off the main burner using the rocker switch.
2. Shut off the pilot flame by turning the pilot knob clockwise to “OFF.”
3. Facing the stove pull open the left side door and open the right side
door by removing the socket head cap screw located underneath the
door near the front of the stove.
WARNING
• Do not attempt to substitute the materials used
on these doors, or replace cracked or broken
glass.
• Handle this glass with extreme care! Glass is
susceptible to damage – Do not scratch or handle
roughly while reinstalling the glass door frame.
• The glass door(s) of this appliance must only be
replaced as a complete unit as provided by the
manufacturer. Do not attempt to replace broken,
cracked or chipped glass separately.
• Do not attempt to touch the front enclosure glass
with your hands while the appliance is in use.
WARNING
Do not operate appliance with the glass front
removed, cracked or broken.
AVERTISSEMENT
Ne pas utiliser l'appareil si le panneau frontal en
verre n'est pas en place, est craqué ou brisé.
