29
Diagram No. Part No. Description
1 H3102 Front Door
2 H5835 Burner Support, Right
3 H5834 Burner Support, Left
4 H3137 Burner Pan
5,6,7 H5872 Brick Panel Set
8 H5836 Brick Panel Bracket
10,11 H3124 Heat Exchanger Kit
12,13 H6014 Side Door
14 H5875 Snap Switch
16,17,24,25,26 H6015 Large Relief Door Assembly
18 H6017 Top Cover
19 H5919 Flue Adapter 6-5/8”
20 H5909 Flue Adapter Gasket
22,23,24,25,26 H3127 Relief Door Assembly, Small
27 H3125 Door Latch Assembly
29 H3126 Magnet and Bracket Assembly
30 H6016 Control Door Assembly
32 H3125 Control Door Latch
33 H5969 Flame Control Extension Knob
34 H5968 Pilot Control Extension Knob
35, 37, 38, 50, 51, 52 H3138 Cassette Assembly, NG
H5942 Gas Control Valve, NG
H5943 Regulator, NG
H5945 Regulator, LP
41 H5744 On/Off Switch, Round
42 H5742 Blower Speed Control (rheostat)
43 H5745 Piezo Igniter
44 H5888 Blower
48 H5896 Fitting Bulkhead
49 H5924 Orifice, NG #36, 33,000 BTU
49 H5973 Orifice, NG #31, 40,000 BTU
51 H5922 Pilot Assembly, NG or LP
52 H5907 Cassette Gasket
53,54 H3078 Blower Grill Assembly
55 H3079 A/C Power Plug
H3077 Power Cord
H5873 Log Set
H5863 Bag of Embers (volcanic stone)
H5864 Bag of Rockwool
REPLACEMENT PARTS - Epic™ 33/40 (EPIC33/40)
WARNING
Failure to position the parts in accordance
with these diagrams or failure to use only
parts specifically approved with this appli-
ance may result in property damage or
personal injury.
AVERTISSEMENT
Risque de dommages ou de blessures
si les pièces ne sont pas installées
conformément à ces schémas et ou si
des pièces autres que celles spécifique-
ment approuvées avec cet appareil sont
utilisées.
Contact an Authorized Lennox Hearth Products dealer
to obtain any of these parts. Never use substitute ma-
terials. Use of non-approved parts can result in poor
performance and safety hazards.
